All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter

All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter

All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter
All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter
All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter
Product Details:
Place of Origin: china
Brand Name: zhaotong
Certification: ISO9001-2015
Model Number: zt-Knitted Wire Mesh
Payment & Shipping Terms:
Minimum Order Quantity: 66kg
Price: negotiate
Packaging Details: plastic bag or woodedn case , or as our customers'requirements
Delivery Time: about 7-10days
Payment Terms: T/T, Western Union, L/C,paypal
Supply Ability: 999kg per 5days
Contact Now
Detailed Product Description
Product Name: All-Metal Mesh Knitted Mesh In Rolls Width250mm Stainless Steel Knitted Wire Mesh For Filter Width: 250mm
Material: All-Metal Name: Knitted Wire Mesh
Shape: In Roll Application: Liquid Filter,automotive,medical,Chemical Industry,Air & Liquid Filtration
Sample: Free Color: Silver
Hole Shape: Round Business Type: Factory
Type: Knitted Wire Mesh OEM: OK
High Light:

oem stainless steel knitted wire mesh

,

filter stainless steel knitted wire mesh

,

width 250mm knitted stainless steel mesh

All-Metal Mesh Knitted Mesh In Rolls Width250mm Stainless Steel Knitted Wire Mesh For Filter





Stainless Steel Knitted Wire Mesh introduce



knitted wire mesh is a wire or plastic strands woven into a mesh structure in a very similar way to socks or sweaters. Knitting production interlocking ring net. These rings can move relative to each other in the same plane without distorting the mesh, giving the braided mesh a bidirectional stretch. Knitted meshes can be crimped or compressed to change characteristics for specific applications. Stainless steel braided mesh has excellent corrosion resistance, alkali resistance, acid resistance, long service life, rust resistance, heat resistance and other properties. Because of these characteristics, it finds popular use in auto parts and other engineering applications.



Stainless Steel Knitted Wire Mesh different forms



Fine Mesh

Typical wire diameter(mm)

Range of natural width(mm)

All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter 0

0.08-0.15

6-160

Typical number of stitches per cm on length

Typical number of stitches per cm across lay flat

3.5

4.5



Medium-fine mesh

Typical wire diameter(mm)

Range of natural width(mm)

All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter 1

0.15

40-635

Typical number of stitches per cm on length

Typical number of stitches per cm across lay flat

2.4

3.5



Standard Mesh

Typical wire diameter(mm)

Range of natural width(mm)

All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter 2

0.2-0.35

30-1000

Typical number of stitches per cm on length

Typical number of stitches per cm across lay flat

1.6

1.8



Coarse mesh

Typical wire diameter(mm)

Range of natural width(mm)

All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter 3

0.2-0.35

30-550

Typical number of stitches per cm on length

Typical number of stitches per cm across lay flat

1.6

0.75



Super Coarse Mesh

Typical wire diameter(mm)

Range of natural width(mm)

All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter 4

0.4-0.5

330-350

Typical number of stitches per cm on length

Typical number of stitches per cm across lay flat

0.5

0.5



Stainless Steel Knitted Wire Mesh application



Embossed knitting wire mesh is a kind of net made by a special technology and a machine with gears. Widely used in automotive, electronics, aviation, military, commercial, industrial consumer goods, telecommunications, medical, testing equipment and accessories and other industries.



Stainless Steel Knitted Wire Mesh Specification



Product name

All-Metal Mesh Knitted Mesh In Rolls Width250mm Stainless Steel Knitted Wire Mesh For Filter

Material

Stainless steel AISI304 304L 316 316L 321,310S,copper,pure silver,tinned copper,monel,pure
nickel wire, titanium wire, monel, galvanized wire,copper wire

Wire diameter

0.20mm

Wire shape

Round wire,Flat wire

Width

250mm,3.8mm,5mm,10mm ,15MM,25mm,30mm,35mm,40mm,300mm,400mm,500mm,600mm,800mm,1000mm

surface Shape

corrugation,twill shape,“W shape”,herringbone

Uasge/application

Generally used in automotive catalytic converters, exhaust systems, noise suppression and shock absorption devices, air conditioning devices, filters, filter components, Marine turbine engine filters, droplet filters, EMI/RFI shielding, industrial filtration, etc

characteristic

High temperature resistance, corrosion resistance, acid and alkali resistance, durable

advantage

easy to install ,Long service life,quality guarantee

Hole

2*3mm,3*3mm,3*4mm,4*5mm,5*6mm

Color

Silver,yellow,black,etc

structure/knitting method

sub-thread,double strand or more

surface treatment

cleanout

technology

Woven,knitted

OEM/ODM

Yes/OK

authentication

ISO9001:2015

serve

Help packing



Stainless Steel Knitted Wire Meshes categories



Meshes can be divided into five categories: fine, medium, fine, standard, coarse and ultra coarse, but these categories can cover a wide range of products. With different wire diameters and mesh sizes, as well as different crimping, calendering, folding, layering and rolling processes, the product range is almost unlimited.



Knitted mesh can also be produced in plastic and other fibres- the most commonly used being polypropylene, glass wool and silica yarn.



All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter 5All Metal Stainless Steel Knitted Wire Mesh In Rolls Width 250mm For Filter 6
